Yoshi's Crafted World

Update 1.0.1 (v65536) over the base game, SDK 4.4.1. Good-Feel's game on Unreal Engine 4.18 era (project PJ033, one PJ033-Switch.pak) with Nintendo's NVN RHI. Modules main and sdk. GMalloc is a FMallocBinned on the process heap (at 0x70f5004000; the libc StandardAllocator is at 0x70f5000000).

Status: brought up on the Mac. It boots, passes the start screen, the play-style menu and the opening, and shows the "How many Yoshis should go?" menu fully textured, with no red line; 10 of 10 muted boots ran clean for 40 s. The Yoshis' felt renders right through the opening since the streamed levels are kept (see Rendering). Plays into the first levels on the Mac (user); from boot with that save, the Mac route reaches the first level's gameplay at about 120 s, with no red line over 250 s. Retested on chain 86c8282f6fb4 (upstream ce9b30b): all 23,497 shaders translate, and over the 150 s route the opening plays at 30 fps with no red line. Retested on chain 7fbca6dd477d (upstream 40e6bae): all 23,497 shaders translate; from a fresh save the step route reaches Rail-Yard Run's gameplay, with no red line over 12 minutes, the menus and opening at 30 fps and the level at 60; on chain d374e783beec (upstream 8334fdf) all 23,497 again, and with that save the timed route reaches the level with no red line over 120 s. Not tested on the iPhone yet (IPA 6.1 GB).

What it needs

Memory

nninitStartup asks for a heap of the pool less used memory, 0xc5200000 bytes. The provisional profile first had the Unreal 64 GB alias region and no heap (SetHeapSize OOM: req 0xc5200000 > cap 0); Unreal games without virtual address memory take a heap.

Rendering

The deferred G-buffer pass writes six targets. Without the texture keys only the normals (smooth, from the vertices) and a mask came out; base colour and the lit scene stayed 0, while the UI drew: packaged textures: first uploads 0. The texture streamer (main+0x2485ea0) copies each cooked mip level into the buffer RHILockTexture2D (main+0x27f5990) returns, and the unlock writes it into the texture's storage, in CPU_UNCACHED | GPU_CACHED pools (flags 0xe2) that take no flush. With the keys: 977 first uploads by that menu.

The streamed textures are sparse (flag 0x20, no packaged layout), DXT1 / DXT5 (0x45, 0x48) and BGRA8 (0x9c), one level each, pre-swizzled in the game's files. RHILockTexture2D sizes its buffer from a per-level table at texture +0x120 that follows the host's level layout (the unpadded level size: 0x78000 for a 960×384 DXT5 level, which the host stores in 0x80000), and the copy takes the cooked size; see Found on this game.

The Yoshis are plain lightmapped static-mesh materials (fragment key a7c457a031dcb113: 1024² DXT1 base colour and BC5 normal, both sampled with a mip bias, an HQ lightmap and a static shadow mask; no shells, alpha test or alpha to coverage), so their felt is in the textures. From the moment the opening went dark they sampled bright speckles and dark blotches, with sharp silhouettes: texraw <serial>.<level> showed levels 0–3 of the base colour intact and level 4 holding another texture (level 4 of the normal all zero). The streamer re-creates a texture with more levels when finer ones stream in, copies the resident levels from the old texture on the GPU (nvnCommandBufferCopyTextureToTexture from main+0x27f5044, Unreal's RHIAsyncReallocateTexture2D) and writes the new levels from the CPU; the host then uploaded the whole texture from its storage, where the copied levels had never been written. Fixed for every game: GPU copies into textures uploaded from their storage.

Mac routes

From boot, A at 22, 25, 28, 31, 34 and 55 s passes the start screen and picks Mellow Mode; Plus then A at 62–70 s skips the opening; A every 10 s from 83 s reaches the "How many Yoshis should go?" menu by about 120 s (DM_CTL, 05-debugging). With a save that has a level unlocked, the same presses continue from the menu into it.

From a fresh save, step by step (DM_CTL, a shot after each step): the play-style menu is up by 20 s, A picks Mellow Mode and a second A leaves its notice; A on the title starts the opening; Plus once the "Skip" prompt shows (from about 40 s into the opening) skips to "How many Yoshis should go?"; A (One), A A (the green Yoshi), A four times through the dialogue reach Sunshine Station's map; A A enters Rail-Yard Run.

The probes that compare the lock size with the copy size: DM_PROBE_ALL=1 DM_PROBE='main:27f5a54@x21+80,main:27f5a58@*x21+68+30,main:27f5a7c,main:2486490' (x9 at 27f5a54 is the lock size, x0 at 27f5a7c the buffer, x19 / x2 at 2486490 the copy's destination and size).

Unreal's purgatory proxy: a romfs overlay (DM_ROMFS_OVERLAY) with UE4CommandLine.txt = ../../../PJ033/PJ033.uproject -purgatorymallocproxy ; the check that reports a modified freed block branches at main+0xae1a4c, parks a block at main+0xae177c (x20, size at [sp+8]) and releases it at main+0xae1a0c (x26).

Found on this game

• Sparse textures of 8- and 16-byte blocks: blocks at most 8 GOBs high: the crashes that moved between runs in 30–70% of boots (allocator asserts, bogus pointers) were 9 streamed DXT5 textures (384×384 to 1920×912) whose level data overran its upload buffer by 0x8000–0x20000 bytes. Found with Unreal's purgatory proxy and read-only parked blocks (05-debugging).
• Unreal games without virtual address memory take a heap: the launch crash of the provisional profile.
• GPU copies into textures uploaded from their storage: the speckled felt once the opening went dark; the small levels of the streamed textures were stale or zero in the host's textures (Rendering).
• Sparse textures smaller than a tile keep the automatic block height: the boot loading icon (five 192×160 DXT5 frames) showed the left half of its chalk drawing and two stray strokes. Resolved: on chain 7fbca6dd477d (upstream 40e6bae) the icon at frame 60 shows the whole drawing; a host without the fix shows the broken one at the same frame; whole again on chain d374e783beec (upstream 8334fdf).
• Image atomics: after c3a0880, the compute shaders 572c1b843ca32afb, 8dbd4ee9b3da30d4 and f0b33a6b4f3cc64f, whose image atomics return a value (an add that hands out slots in r32ui buffer images, an exchange that swaps list heads), failed translation, and a texture_buffer image read as 2D stopped the host at frame 84 ("image atomics: unsupported or overflowing IMG extent"; Buffer image reflection keeps its texture type). Resolved upstream by e72991d (the host) and 2e655b7 (the translator); since f8642c4 the three run as Metal's native texture atomics on their buffer images (retested on chain a4e2088c2e69).

Open

• The iPhone (IPA 6.1 GB; 3.15 GB heap: check the memory it needs there).
