Well Dweller

Version 1.0.0, SDK 22.2.0 (nnSdk-22_2_0, NintendoSDK_NVN-22_2_0, NintendoSDK_OpenGL-22_2_0). A GameMaker Studio 2 game: the RomFS holds the runner's data file (game.win, 229 MB, FORM/GEN8), its entitlements, three audiogroup*.dat banks, options.ini with [LLVM-Switch] SDKDir=…, and its pictures.

It renders with OpenGL, not NVN: main imports exactly nine EGL entry points (eglChooseConfig, eglCreateContext, eglCreateWindowSurface, eglDestroySurface, eglGetDisplay, eglGetProcAddress, eglInitialize, eglMakeCurrent, eglSwapBuffers) and every GL function through eglGetProcAddress. The context is OpenGL 3.2. Modules main, subsdk1 (NintendoSDK_movie) and sdk; subsdk0 (NVIDIA's GL driver) is never loaded.

On the Mac: the language list, the title screen, the opening story and the first room with its dialog render at 60 fps with sound, played with the keyboard (WASD + J/K) or a pad.

What it needs

Rendering (OpenGL)

• Shaders at run time: the runner writes each variant of its GLSL as text, in GLSL ES 1.00 without a #version line (attribute, varying, gl_FragColor, precision mediump), names a variable sample, and declares its light environment and a few others as struct uniforms (uniform LightEnv { … };, which the game addresses by dotted member names such as u_LightEnv.m_dirLights_dir). Both needed the translator: GLSL ES 1.00 sources without a #version line, Struct uniforms become member rows.
• Draws from client memory: every sprite, the room background and the screen composite are drawn from client-memory vertex arrays (glVertexAttribPointer with no buffer bound); only the text path uses a real buffer, which is why the window first showed text alone. Dropped draws went from 11,885 per 300 frames to 0: Draws from client memory.
• Two targets: the runner renders its room into a 1280x720 surface of its own (framebuffer 1, colour texture 5) and composites that surface onto the 1920x1080 window with one 4-vertex GL_TRIANGLE_STRIP sampling texture 5, whose matrix has a negative y scale, since the runner keeps its surfaces y down while the window is y up. A second surface (framebuffer 2, colour texture 189) carries the rotation and scaling of the first. So a draw log that shows 1280x720 targets under a window that looks right is expected here.
• glFlush at the pause menu: the runner calls it when it opens the menu; without it the game jumped to address 0 (CRASH sig=11 addr=0 pc=0 lr=main+0x3409a78): glFlush hands the frame so far to the GPU.
• Small gaps filled while bringing it up: glDepthRange / glDepthRangef (0..1 only), GL_DEPTH_CLAMP (Metal clamps to the depth range already) and GL_MAX_TEXTURE_MAX_ANISOTROPY (16).

Shaders

• Current: 93 sources in gl_capture.tsv — the runner's sprite, text, lighting, fog and outline programs and their variants — captured on the Mac with DM_GL_CAPTURE and translated to one .metallib by gl_shaders.py. The set is stable from boot through the first room's dialog; a room with an effect no earlier scene used would add one, which the capture table makes the build report.

Audio

• With DM_AUDIO=1 on the Mac the first room's music plays: 0 underruns after the boot's first 194 padded callbacks.

Found on this game

General host changes first needed here; each applies to every game on the same SDK or path:

• Resolved: ZBIC modules (NSO flag bit 7, system 22.0.0 on): main could not be read at all: ZBIC-compressed NSO segments.
• Resolved: the thread ID at ThreadLocalRegion+0x110 (SDK 22): an nn::diag abort with Result 0 at the first heap lock, in main's static initialisers: The thread ID at ThreadLocalRegion+0x110 (SDK 22).
• Resolved: clock_gettime(CLOCK_MONOTONIC) (SDK 22): an uncaught std::system_error from std::chrono::steady_clock::now(): clock_gettime is nn::time's steady clock (SDK 22).
• SDK aborts with a message (nn::diag::detail::VAbortImpl) log their format before the abort, which is how the system_error above was named: clock_gettime is nn::time's steady clock (SDK 22).
• Resolved: no audio, OpenAudioOut without a release event (SDK 22): OpenAudioOut without a release event (SDK 22).
• Resolved: a crash at pc 0 in nv::GetGraphicsMemoryInfo on a title with no NVN device: nv::GetGraphicsMemoryInfo with no graphics device.
• The GL layer: client-memory vertex arrays, glFlush, and the bring-up switches DM_GL_DRAWLOG, DM_GL_FBLOG and DM_GL_MISSES (see env_switches.tsv); the translator's ES 1.00 dialect and struct uniforms (links above).

Open

• save:/Settings.sav is never written. The runner asks the language on every launch (fs path not found: save:/Settings.sav, then save:/Settings.sav is not on the RomFS either). save:/WELLDWELLER/blob.sav is written and committed (save commit #1 … swapped atomically), so the save mount works: the settings file is written on a clean quit, which the host's kill does not give the runner.
• Verified up to the first room, its dialog and the pause menu (OPTIONS with its CONTROLS/GRAPHICS/AUDIO/GAMEPLAY tabs, STATS, PAGES, MAP). Later rooms, the map itself and the save flow after a room are unverified.
• Audio and video were not measured against each other (the report of DM_AUDIO_DUMP shows music, and the video runs at 60 fps, but no lip-sync or cutscene timing was checked).
