- Title ID
- 0100698009C6E000
- Tested build
- 1.0.8
- Nintendo SDK
- 8.3.1
- Engine
- Unity 2017.4.28f1 IL2CPP, FMOD
- Graphics API
- NVN
Build this game
Keep [0100698009C6E000] in your file names, put the base game, update and DLC in one folder and run the script. Follow the build guide, then the sideloading guide. Needs an iPhone 15 Pro or newer, or an M1 iPad or later.
Technical notes
The project's own record of bringing this game up: what its profile needs and why, what was found and what is still open.
Update 1.0.8 (v524288) over the base game, SDK 8.3.1, Unity 2017.4.28f1 IL2CPP with FMOD on NVN. Modules main, subsdk0 (NintendoSDK_movie) and sdk. Plays on the Mac: title, patch notes, new game, opening H.264 cinematic, awakening, healing, movement, jumping and a sword swing in the first room. Gameplay testing deliberately stops there. iPhone/iPad validation remains open.
What it needs
| Setting | Where | Why |
|---|---|---|
sys_resource 0 |
game.tsv |
The NPDM declares no system resource, so Unity uses a heap rather than virtual address memory |
4 GB guest block, 3.25 GB heap region, app_pool 0xCD500000 |
game.tsv |
The standard older-Unity layout; the startup heap request is 3.10 GB |
mem_used 0x7000000 |
game.tsv |
The rewritten modules exceed the default 64 MB; the packing script calculates 112 MB so the requested heap fits beside them |
shader_groups /Data/=data |
game.tsv |
The serialized files and AssetBundles are under Data/ |
depth_mode zero |
game.tsv |
The game sets near=0 at startup; offline pipeline bases use the matching vertex entry point |
No game-specific rewriter cut or host change. The general forward-initialized jump-table fix below is required to rewrite main.
Files and shaders
- The merged RomFS has 4,417 files, 6.07 GiB, including 99 UnityFS bundles, the player's serialized assets, 13 MP4 movies and FMOD banks.
- The DLC NSP is a licence-only package, index 1 (
0100698009C6F001); packing recognizes the licence. Its content was not separately tested. - 617 shaders: 304 vertex, 301 pixel and 12 compute. Four GLSLC outputs are in
main; the other 613 come from Unity assets. All compile on the Mac, with zero unresolved bindings or unfillable driver-bank reads. - The legacy Unity supplemental pairs plus the serialized pair give 309 pipeline bases; all 309 prebuild successfully.
pso_manifest.tsvrecords the checked opening route's 43 unique shader/pipeline entries. - All 617 shader libraries compile for iOS too. The unsigned IPA is about 0.9 GB (877.5 MiB), built for user sideloading; device runtime validation remains open.
Performance and validation
- Tested on the Mac on 2026-10-28, in a five-minute startup and opening-room run. No runtime
[RED]message, abort or crash. The process was stopped after the short control check. - The first room presents at the game's 60 fps target. Settled 300-frame windows report frame-time p50 about 16.67 ms and GPU p50 about 0.8–1.7 ms. Other builds were active, so these are diagnostic observations rather than an isolated benchmark.
- Resident memory settles around 1,936–1,938 MB in the opening room, with Metal allocations around 2,054–2,055 MB; no sustained growth in the checked interval. This is a brief check, not a long-session leak test.
- FMOD opens one AudioOut. Settled callback windows report zero underruns. The movie module produces visible H.264 pictures and subtitles.
- The Python tool suite and
make -C dm/gfx/tests GAME=0100698009C6E000 runpass. The rewriter's new fallback has synthetic tests for bounds, base clobbers, incoming branches, invalid targets and table extent. The IPA passesunzip -tq; its six shipped profile tables match the repository copies. regress.py check --quickchecked Return of the Obra Dinn (the closest Unity 2017.4 compiler) and Super Mario Bros. Wonder (an established x18 rewrite route). Two games are sufficient for this narrow fallback: every previously recognized site takes its old path, and all five rewritten modules of these games are byte-identical to the baseline. All 17,540 shader outputs and pipeline interfaces are unchanged; both routes reach their frame targets with zero new[RED]kinds. Wonder reports PASS. Obra Dinn reports REGRESSION for FPS 59.8 → 53.4 in the measured window; both runs are marked busy with concurrent jobs, so the performance comparison is inconclusive. Its screenshot changes (RGB 8.5 and 7.97) show a different rowing-animation phase on visual review. The earlier full Obra Dinn run measured 59.9 → 59.1 fps with no runtime errors. The final report is in the NSP work folder'sregress-quick-report/report.md; other games were not checked.
Mac route
Build with scripts/build_ipa_from_nsp.py <NSP folder> -k <prod.keys> --platform mac and use its printed command. At the title press A, dismiss the first-run patch notes with B, press A on Pilgrimage, then A on the first empty slot. Let the opening advance; B can skip a cinematic segment when enabled.
The opening room initially requires L to heal before movement is available. Dismiss the Biliary Flasks tutorial with B. Left stick moves, B jumps and Y swings the sword. The default 2D touch-pad layout exposes these controls.
The checked route used a windowless diagnostic run (DM_PRESENT_LINK=0, omit DM_WINDOW) with audio and DM_CTL screenshots. The save contains the first new-game slot; save reload was not tested.
smoke.tsv is a short fresh-save title-screen route, without input or gameplay. A second 40-second boot checked the registered profile and final rewritten modules.
Found on this game
- Offset table base initialized after the dispatch: the general rewriter fix, found at
main+0xae95f8. - Existing Unity 2017.4 shader containers and Unity video planes work without another change.
Open
- iPhone/iPad runtime validation, save reload, combat encounters, bosses, later areas and DLC content. The base version was inspected for build lookup but was not played or registered.
- An isolated repeat of the noisy Obra Dinn performance comparison above; no claim of an existing-game performance improvement or regression follows from these busy-Mac timings.
