- Title ID
- 010076F0049A2000
- Tested build
- 1.1
- Nintendo SDK
- 3.6.0
- Engine
- PlatinumGames' engine (Wii U form)
- Graphics API
- NVN
Build this game
Keep [010076F0049A2000] in your file names, put the base game, update and DLC in one folder and run the script. Follow the build guide, then the sideloading guide. Needs an iPhone 15 Pro or newer, or an M1 iPad or later.
Technical notes
The project's own record of bringing this game up: what its profile needs and why, what was found and what is still open.
Update 1.1 (v65536) over the base game, SDK 3.6.0. PlatinumGames' own engine in its Wii U form on NVN, as Bayonetta 2: the same sdk and subsdk0 builds (subsdk0 is NVN's GLSLC, which main imports), and no host change. CRI middleware throughout: the file system (CPK), ADX2 sound (se/ and bgm/, .acf / .awb) through one 6-channel AudioOut, and Sofdec movies (USM), all decoded by the game's own code. Plays on the iPhone (IPA 8.8 GB). Its profile is Bayonetta 2's with its own build row and tables.
On the Mac from a fresh save: the boot, the opening movie (USM; Plus skips it), the title and its attract demo, a new game (PLAY, NEW GAME, the auto-save notice, Normal), the prologue on the falling clock tower, the graveyard cutscene (skipped: Plus, Down, A, then Left, A for Yes), the touch-controls tips, the practice tutorial (punch, kick, combos, evade, Witch Time), the graveyard fight of Verse 1 with Witch Time, its autosave and the next loading screen's practice, with sound and no red line. 60 fps in play (frame time p50 16.65 ms, p95 17.1–17.5 ms; GPU 2–4 ms a frame on an M6), 30 in its cutscenes, where the game sets present interval 2; about 2.45 GB resident and 1.54 GB of Metal allocations, flat over 15 minutes.
What it needs
| Setting | Where | Why |
|---|---|---|
4 GB layout: mem_reserve 0x100000000, mem_alias 0x10000000, mem_stack 0x10000000, app_pool 0xCD500000 |
game.tsv |
the 4 GB block of the other games without virtual address memory (256 MB in front + 256 MB alias region + 256 MB stack region + 3.25 GB heap region) |
sys_resource 0x0 |
game.tsv |
the NPDM declares no system resource (META +0x14 = 0): nninitStartup sets a heap of the pool − used memory (3.11 GB) |
mem_used 0x6600000 |
game.tsv |
the rewritten modules (102 MB) are larger than the default 64 MB of used memory, and the game's SetHeapSize asks for pool − used |
pad_layout full |
game.tsv |
the 3D pad layout: the camera is on the right stick. The touch controls are handheld only; the profile keeps it docked |
shader_groups /shader.dat/=core |
game.tsv |
the one shader DAT |
zip_store .awb:.cpk:.usm:.metallib |
game.tsv |
already-compressed files stored as they are in the IPA |
Files and shaders
- Nine CRI CPK archives in the RomFS root (
data00.cpk…data03.cpk,data10.cpk…data14.cpk, 4.25 GB) of PlatinumGames DAT archives, beside the movies (movie/) and the sound;cpk.pyreads them as they are. - Current: 458 BNSH files of one stage each (236 pixel, 222 vertex), the
.vso/.psomembers ofshader.datindata00.cpk(CRILAYLA); the split (cpk_jobs) takes about 1.7 minutes. All build, and the picture was right on the route to the first fight (the clock tower, the graveyard, Witch Time's tint, the practice screens, the HUD) with no change: the two fixes made for Bayonetta 2 cover this engine. - A prewarm list recorded on the Mac over the route above (513 lines).
Game state
- The prologue's practice tutorial waits on a Witch Time page until a dodge lands right before the strike (the work folder's
run/witch.pytimes it; it took 20–30 tries).
Mac input
The work folder's run/see.sh <run> [secs] boots on a fresh save (or SV=<save>), presses PRESS once frame AT is logged and takes a shot every EVERY s; run/ctl.sh, run/step.sh, run/watch.sh and run/fight.sh as for Bayonetta 2; run/tut.sh works through the practice tutorial's pages (Minus is Next), and run/witch.py times the Witch Time page's countdown from shots and dodges at a sweep of offsets. run/save_ref is the save at the prologue's chapter screen, run/save_ref2 the checkpoint after the tutorial (the tutorial comes back after a load), run/save_ref3 the one after Verse 1.
Found on this game
Nothing new: the CPK reader and the two rendering fixes made for Bayonetta 2 cover it.
Open
- Nothing known.
