Balatro

Update 1.1.3 (v851968), SDK 18.3.2. LÖVE 11.4 ("Mysterious Mysteries", love-nx) with LuaJIT 2.1.0-beta3 in its interpreter and SDL: the game is Lua source in the RomFS (main.lua, game.lua, engine/, functions/), its pictures PNG, its sound Ogg Vorbis through OpenAL Soft on the audio renderer. It renders with OpenGL, not NVN: NVIDIA's desktop GL 4.5 through EGL, which the host implements on Metal (dm/gfx/gl/hle_gl.m) on the core profile's paths. Modules main and sdk; sdk is the same build as Absolum's (0100A83022A22000). subsdk0 (NVIDIA's OpenGL driver) and subsdk1 (NVIDIA's Vulkan driver) are never loaded. Plays on the iPhone (IPA about 82 MB), by touch in handheld mode.

On the Mac: the intro, the title, a new run by touch and the tutorial's first steps, at 60 fps with sound; about 0.65 GB resident and 0.2 GB of Metal allocations, flat over three minutes in a run.

What it needs

Rendering (OpenGL)

LÖVE's graphics module is its own OpenGL backend, so its choices follow what the context reports.

• Telling the API apart: main imports the EGL functions and vkGetInstanceProcAddr, SDL's Vulkan loader, which nothing calls. Resolved: the NSP script's provisional profile said Vulkan, and the capture boot crashed in the GL layer; profile_guess.py now leaves vkGetInstanceProcAddr out of its Vulkan count (Hades and both Galaxies import 99 or 100 Vulkan functions, vkCreateInstance among them).
• Which GL functions: LÖVE's glad loader asks for 2,133 GL names and stores each pointer straight into a global of its own (no GOT slot per name). The code reaches those globals through GOT entries that hold their addresses, which it often keeps in callee-saved registers across a loop, or picks between with csel (glEnableVertexAttribArray or glDisableVertexAttribArray). loader_census.py follows registers in a straight line for that (adrp, add, loads through relocated GOT entries, mov, csel): about 150 called.
• Resolved: a jump to address 0 right after glGetFloatv(0xb12) (lr=main+0x2d58c4): a GL function the layer did not have (here glVertexAttrib4fv, LÖVE's default colours). DM_GL_STUBS=1 gives every name the layer lacks a stub of its own that reports its first call instead of a null pointer (a jump to address 0 names nothing); loader_census.py lists what the code calls before the first boot.
• Core profile: LÖVE reads GL_CONTEXT_PROFILE_MASK, which the layer now answers as core. On a core profile it streams vertices through persistently mapped buffers (glBufferStorage + glMapBufferRange of a 3-frame ring, a glFenceSync per frame and glClientWaitSync three frames later); on a compatibility one it would draw from client memory, which Metal cannot draw from. In the layer the mapping is the shared MTLBuffer's memory, a fence is the serial of the command buffer being recorded, and a wait on a fence of that command buffer commits it first. The shaders then come as #version 330 core.
• Attributes: LÖVE binds VertexPosition, VertexTexCoord, VertexColor and ConstantColor to 0–3 with glBindAttribLocation before each link, keeps VertexColor and ConstantColor as disabled arrays and sets their values with glVertexAttrib4f (the draw colour); the layer maps each Metal input to the game's index at the link.
• Uniforms: LÖVE lists them with glGetActiveUniform (types as GL enums, arrays as name[0]) and reads their initial values back with glGetUniformfv / iv; every glUniform* form.
• Textures: made with glTexStorage2D (every level up front: the game's images are mipmapped, filled by glGenerateMipmap as a blit) or glTexStorage3D: LÖVE makes a 1x1 default texture of each type, 3D and 2D array among them, and the layer's units hold all four targets (96 of them, as GL_MAX_COMBINED_TEXTURE_IMAGE_UNITS says). Font glyphs are RG8 with a GL_TEXTURE_SWIZZLE_* of R, R, R, G, applied when the texture is made (a swizzled texture cannot be a render target).
• Draws and framebuffers: batched quads share one 16-bit index buffer through glDrawElementsBaseVertex; instanced draws; canvases bind GL_FRAMEBUFFER (read and draw), check completeness, discard depth and stencil after use (glInvalidateFramebuffer) and clear with glClearBufferfv. Separate read and draw framebuffers, glBlitFramebuffer (colour, same size) and glReadPixels (RGBA8) are there for multisample resolves and Canvas:newImageData, which the game does not use.

Shaders

• Current: LÖVE puts each shader's GLSL together at run time, in Lua, from its own header and built-in code and the game's 19 resources/shaders/*.fs: 35 sources (#version 330 core), all made by Game:start_up before the first frame. No game file holds them, so the NSP script captures them on the Mac (DM_GL_CAPTURE at <id>_build/extract/<version>/gl_capture until every file in gl_capture.tsv is there) and gl_shaders.py translates them; the host finds each by the hash of its text.
• Resolved: a GLSL bool uniform is a uint in SPIR-V; gl_shaders.py now reports the declared type, since LÖVE's Shader:send takes only a boolean for a bool (the game stopped at its first card otherwise).
• A capture run has no shader library: every program then links with no uniforms, and the game's first Shader:send raises a Lua error, which quits (below), after every shader is captured.

Audio

• Resolved: silent. The game opens the audio renderer without an event (OpenAudioRenderer(handle, parameter, work, size), from LÖVE's OpenAL Soft) and paces its own updates; the renderer must still run every 5 ms. The host started its render thread only for the form with an event, so only the game's own updates rendered (catch-up frames that nothing played). Both forms now go through one open that starts the thread (hle_audren.c ar_open). The log showed audren: OpenAudioRenderer (no event) and no render thread started.

When the game stops

• On the Switch, Balatro's love.errhand returns at once, so any Lua error quits. love-nx's video worker is then deleted twice (love::video::theora::Video → ~Worker: its thread releases the worker that the closing video module also deletes), which crashes in main+0x339c00 a second or two into the title. A run that reaches this has hit a Lua error first: look for it.
• How it was found: a print at the top of love.errhand in main.lua, in a copy of the RomFS (DM_ROMFS=<copy>), gave the errors: Shader uniform 'distortion_fac' does not exist (the capture run had no shader library, so every program linked with no uniforms), then bad argument #2 to 'send' (number expected, got boolean) (a bool uniform reported as GL_UNSIGNED_INT). Probing the destructors (DM_PROBE) and logging every object the Lua GC released (DM_PROBE=main:0x18b920@x0+0: the module proxies all at once) showed it was a shutdown, not a premature collection.

Rewriter

• The spin-wait search through stores found 12 loops in main instead of 9; one is a parser state that leaves on the next pass (main+0x1f4600) (development.md, Power).

Mac routes

• In handheld mode, DM_KEYS="f1300:T0.35x0.86,f1700:T0.35x0.86,f2100:T0.5x0.68" taps Play at the title, Play in the run setup and the tutorial's Next.

Found on this game

General host changes first needed here; each applies to every game:

• Resolved: Homebrew .NET runtime discovery for the first extraction and shader tools: Homebrew .NET is on PATH but apphosts cannot find the runtime.
• The GL layer's core-profile paths (GL_CONTEXT_PROFILE_MASK, persistently mapped buffers and fences, attribute bindings and current values, uniform queries, texture storage, 3D and array textures, swizzles, mipmaps, base-vertex and instanced draws, blits) in hle_gl.m, and DM_GL_STUBS=1: The GL core profile and persistently mapped buffers, GL uniforms, pipelines and attributes, GL textures, swizzles and uploads, GL draws and framebuffers, Which GL functions a game calls.
• loader_census.py following registers (LÖVE's glad), and vkGetInstanceProcAddr left out of profile_guess.py's Vulkan count: same section.
• GL shaders captured at run time (DM_GL_CAPTURE, gl_capture.tsv, the NSP script's capture_shaders): development.md, The packing script in detail.
• A renderer opened without an event starts the render thread (ar_open): A renderer opened without an event.
• The Tap pad layout (pad_layout touch, DmGamepad.m): dm/games/README.md.

Open

• The player-facing README says the games outside its 2D list start in the 3D layout; Balatro starts in Tap (its gallery entry says "played by touch").
